Clinical Case: Full-mouth rehabilitation using injection molding technique

with 3M™ Scotchbond™ Universal Plus Adhesive and 3M™ Filtek™ Supreme Flowable Restorative.

Ana Roig

Read post

About the Case

A male patient in his mid-40s showing severe signs of erosive wear. Full-mouth rehabilitation was indicated to stop lesions progression and get the original vertical dimension back. Orthodontic therapy was planned as first step for better alignment before the restorative execution.

Challenge

The main challenge lies in restoring function and VDO in a severely eroded dentition while balancing adhesion, occlusion, and longevity using a minimally invasive and economical approach.

Close-up of upper and lower teeth showing wear and discoloration with two smaller images of upper and lower dental arches from inside the mouth

Pre-op situation after aligners therapy. Multiple erosive lesions are visible.

Close-up of upper front teeth showing discoloration and wear on the central incisors

Old composite removal and enamel conditioning with 29 μm alumina.

Close-up of upper front teeth with blue dental material applied to some teeth and one central tooth partially covered

Enamel etching for 15 seconds on teeth to be restored in the first round.

Close-up of upper front teeth with white dental material applied and a brush touching one tooth

Application of 3M™ Scotchbond™ Universal Plus Adhesive after protecting non-injected teeth with PTFE tape.

Close-up of a dental mouthguard fitted over upper teeth with a dental scaler tool positioned underneath

First silicone matrix in place, ready to inject teeth 14, 12, 21, and 23.

Close-up of upper front teeth with a transparent dental appliance covering them and small white material drops on the appliance

Injection of 3M™ Filtek™ Supreme Flowable Restorative B1 shade.

Close-up of upper front teeth showing one central incisor with a large chip and discoloration

First four teeth restored after excess removal.

Close-up of upper front teeth with white dental material applied unevenly on several teeth and gums visible above

Situation after the second-round injection following the same procedure.

Close-up of upper front teeth with blue dental material applied on some teeth in the top half and a brush applying a substance to the teeth in the bottom half

Etching enamel and adhesive application on lower arch teeth.

Close-up of upper front teeth with dental appliance and lower front teeth showing gum recession and tooth wear

Same procedure of injection molding on lower arch.

Dental impression tray with visible teeth and three vertical posts inside the mouth

3M™ Filtek™ Supreme Flowable Restorative injected. Excess removal outside the matrix is recommended before light-curing.

Close-up of upper and lower teeth showing slight crowding and mild gum recession with two smaller images showing upper and lower dental arches from above and below

Immediate post-op situation after finishing and polishing, including posterior teeth.

Outcome

Composite injection molding is established as long-term interim treatment and offers significant advantages, but success depends on precise planning, etiological control, and meticulous execution.

3M™ Filtek™ Supreme Flowable Restorative has appropriate optical properties for life-like results, offers excellent polishability, and wear resistance.
